Limit switch 3/2 NC unidirectional cam pneumatic 3/2 NC monostable with side fittings M5 diameter - Aignep

Limit switch 3/2 NC unidirectional cam pneumatic 3/2 NC monostable with side fittings M5 diameter - Aignep

€18.26 Tax included

€15.09 tax excl.

Limit switch pneumatic with unidirectional M5 cam actuator 3 way and 2 positions, fittings located on the side for tube outside diameter M5. The type of limit switch valve is normally closed (NC).

Series: 02V
Part no.: 02VU03NCB5

ESQUEMALEVA Logotipo AignepNORMATIVAMICROVALVULA

Representative image for illustrative purposes, the item supplied will correspond to the specifications shown.

No queries yet, leave the first!
Privacy
Shipments
Returns


Limit switch the pneumatic valve is actuated by means of a unidirectional cam, with integrated quick-connect fittings for M5 external diameter pipe. The valve's idle state is normally closed (NC), i.e. when not pressed there is no air at the outlet, as air cannot pass through, and when actuated it lets air pass through and there is pneumatic pressure at the outlet.

Manufacturer: Aignep

  • Part number: 02VU03NCB5
  • Thread: M5
  • Valve body: anodized aluminum
  • Spring material: stainless steel
  • Seals: NBR
  • Fittings: quick couplings for pipe diameter M5 side connection.
  • Operating pressure: 2 ÷ 10
  • Operating temperature °C: -10 ÷ +60
  • Flow rate at 6 bar ΔP 1 bar Nl/min: 100


02VU03NCB5

Material for professional use, install in compliance with the regulations in force at the place of installation.

For further information you can download the technical data sheet by clicking on the "Attachments" tab
