63A 30mA, 4-pole, electromagnetic type electrical differential switch for protecting people from insulation/derivation problems in installations or electrical elements. High conditional cutting power (10kA).
Employment class "A", high inmunicado in the presence of disturbances in the power line. Advanced neutro shooting over the phase, neutral position on the left side.
This type of differentials are electromagnetic operating, which allows not to lose the safety function in case of variations in supply voltage or loss of the neutral conductor. Only with the derivation in the active phase does the differential fire occur.
Manufactured in moderate and fireproof thermoplastic material. It has two visal indications of status on the front, the upper indicates the status of the diferecial (ON/OFF) and the lower indicates leakage current failure. This differentiacial supports mounting auxiliary elements on the sides.
Technical details:
- Manufacturer/Importer: omu systems
- Model: OMR104A63003
- Number of poles: 4 (3+N)
- Class: A
- Type: electromagnetic
- Employment in tertiary and industrial sector
- Operating voltage (Eu): 240/415 VAC.
- Nominal intensity (In): 63A
- Sensitivity ( I'n): 30mA (0.03A).
- Cutting power: 10kA
- Insulation voltage (In): 500 V.
- Degree of protection IP20.
- Visual indication of contact position: Red-ON, Green-OFF.
- Regulations: IEC/EN 61008-1
- CE marking
- Terminal size: 50 mm2
- Net weight (Kg): 0,410
- Mounting position: Vertical/Horizontal.
- Housing and cover: Molded thermoplastic material, fireproof.
- Possibility of double connection by cable or comb
- Auxiliary elements: NO
Dimensions:
