Bearing 7312 FAG 60x130x31mm
Bearing 7312 FAG 60x130x31mm

Bearing 7312 FAG 60x130x31mm

€122.02 Tax included

€100.84 tax excl.

Ball bearing 7312 single row angular contact,dimensions 60x130x31mm. Angular contact one-row bearing, made of steel and cage for the balls in polyamide.

Reference: 7312 B-XL-TVP

Logo-FAG

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!


Angular contact ball bearing, one row, 7312 series according to DIN 628-1, without any kind of opturing (open). Cage made of reinforced PA66 polyamide.

One-row angular contact ball bearings withstand high radial loads and axial forces in one direction, the contact angle of this series is 40o. The usual mounting of this type of bearings in combination with another bearing.

This type of bearings are suitable for operating temperatures from -30oC to +110oC.

Dimensions: 60x-130x31.

For other references or measures consult.

DibujoRodamientoAngularFAG

characteristics:

  • Manufacturer FAG.
  • Reference: 7312 B-XL-TVP.
  • Material: Tempered steel.
  • Cage: In polyamide
  • Dimension d: 60mm.
  • Dimension D: 130mm.
  • Dimension B: 31mm.
  • Shutter: No, bearing open on both sides.
  • Dynamo load capacity Cr (N): 96000.
  • Static load capacity C₀r (N): 69000.
  • Contact Angle: ἀ-40o
  • Limit speed ng (min⁻1): 5600.
  • Weight: 1.72Kg.

Material for professional use, install in compliance with the regulations in force at the place of installation.
