Valve 1/4 5-way 3 positions closed centers - Mindman

Delivery in 3 days
€52.56 Tax included

€43.44 tax excl.

MVAA2204A2C

Pneumatic valve of 1/4 5 ways 3 positions closed centers, pneumatic control, metal body. For control of double effect cylinders.

Reference: 281MVAA2204A2C

Esquema neumático valvula 5/3 centros cerrados
https://rodavigo.net/datos/logos-marcas-png/th_mindman.png

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

1 question about the product
Privacy
Shipments
Returns


Pneumatic valve of 1/4 5/3 closed centers, pneumatic drive that allow to control double-effect cylinders.

The valve has 3 positions, activating one inlet the cylinder advances, without activating any cylinder stops, does not let air out of the sides of the cylinder, the cylinder maintains force, and activating the other inlet the cylinder is collected.

Technical details:

  • Manufacturer: Mindman.
  • Manufacturer's Reference: MVAA-220-4A2-C.
  • Configuration: 5 ways 3 positions, closed centers.
  • Thread type: G 1/4".
  • Type of exhaust threads and control: G 1/8".
  • Number of tracks: 5.
  • Positions: 3.
  • Fluid type: Air under pressure, with or without lubrication.
  • Working pressure: 0÷8 Kgr/cm2.
  • Piloting pressure: 1.5÷8 Kgr/cm2.
  • Maximum pressure: 10 Kgr/cm2.
  • Effective pitch diameter: 18 mm2.
  • Working temperature: -5 to 60oC.
  • Material: Aluminum and steel.

For other models consult. You can download the catalog by clicking on the DOWNLOADS tab.

Dimensiones valvulas neumaticas 1/4-5/3 Mindman

Questions

Question
una electro válvula 5/3 se puede combertir en 5/2" el problema es que, cuando hay corte de energia improbisado las compuertas quedan abiertas y el producto se descarga sin control. cómo me podrian apoyar en ese problema gracias de antemano atte. mario paz ch.
Answer
Estimado cliente, si es una electroválvula de 5/3 centros cerrados, mientras la electroválvula este desconectada, los centros estan cerrados, ahora bien, no sabemos porque desea convertirla en 5/2. Si desea una electroválvula 5/2 es mejor directamente poner una electroválvula 5/2.

Un saludo
ADAJUSA
mário paz ch. on 09/27/2022 17:37:53
