6000VA ultra-isolation IP-20 transformer
6000VA ultra-isolation IP-20 transformer

Transformer 6000VA 230/230Vac ultra-isolation IP-20

Special manufacturing material
€517.18 Tax included

€427.42 tax excl.

TRIA6000

6000VA primary 230Vac secondary 230Vac single-phase transformer,intended for circuit power supply where galvanic separation of follow-up and filtering of disturbances is required.

Manufactured in resin encapsulator, protection grade IP-20.

Reference: TRIA6000-230-230

esquema transformador monofásico con pantalla 230-230

1 question about the product
Privacy
Shipments
Returns


6000VA ultra-insulated single-phase transformer,for control and manoeuvre in electrical circuits where galvanic separation of safety and filtration of disturbances is required. They are manufactured at various primary and secondary stresses.

Ultra-insulated transformer with pharadic kick. Separation of primary and secondary circuits from a safety electrostatic display that filters and grounds unwanted signals and disturbances. The degree of leaking will depend directly on the quality of the grounding of the installation.

Manufactured with resin encapsulation that provides an IP-20 degree of protection.

Technical characteristics of the transformer:

  • Reference: TRIA6000-230-230
  • Available primary/secondary voltages: 230/230Vac
  • Transformer power: 6000 VA.
  • Windings: Thermal class N 200oC.
  • Insulators: Thermal class B 130oC.
  • Frequency: 50/60 Hz.
  • Protection: IP-20.
  • Transformer test voltage:
    • 5 KV between windings.
    • 2.5 KV between windings and dough.
  • Ambient temperature: Tao 25oC.
  • Transformer encapsulation: Self-extinguishing resin.
  • Transformer mounting: using screws.
  • Certificate: UNE-EN61558

Indicaciones de medicas transformadores monofasicos en resina

Table dimensiones transformadores monofasicos TRIA

Esquema electrico transformador separador con triple pantalla

Questions

Question
Buenas tardes He instalado una aerotermia que consume un máximo de 25A a 230V (unos 6kw) Necesito un trafo para pasar la tensión que tengo de acometida que es bifásico (115V+115V) a monofásico (0V+230V). Que transformador es el adecuado?
Answer
Buenos días,

Necesitaría un transformador monofásico de ultraaislamiento de 10KVA ( hay que tener en cuenta que el cálculo de la potencia es necesario hacerlo con un sobredimensionamiento del 20% para el correcto funcionamiento del trafo)

https://adajusa.es/es/transformadores-monofasicos/11413-transformador-monofasico-10000-va-230230v-ultra-aislamiento-caja-ip23-8445340114130.html

Llevando uno de los bornes de salida a una pica de tierra independiente a la del resto de la instalación en caso de que necesite generar neutro.

Quedamos a su disposición para cualquier otra consulta,


Un saludo

ADAJUSA
Álvaro on 12/01/2022 18:51:56
