Limit switch 1/8 3/2 NC strut pneumatic - monostable with spring return Aignep

€24.99 Tax included

20.65 tax excl.

03VG03NC02

Limit switch pneumatic 1/8 3 way and 2 positions, for mounting with emergency push button or similar. Actuated by spring return mechanical strut.

Series: 03V
Reference: 03VG03NC02

esquemaretornopormuelle Logotipo Aignep NORMATIVAMICROVALVULA

Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!
Privacy
Shipments
Returns


Limit switch pneumatic 1/8 3 way and 2 positions, normally closed (NC), monostable, actuated by spring return mechanical strut. Limit switch connections are by 1/8" thread (fittings located on the side of the valve).

Manufacturer: Aignep

  • Part No.: 03VG03NC02
  • Valve body: anodized aluminum
  • Spring material: stainless steel
  • Seals: NBR
  • Actuating force: 19,6 N
  • Operating pressure: 2 ÷ 10
  • Operating temperature °C: -10 ÷ +60
  • Flow rate at 6 bar ΔP 1 bar Nl/min: 350


03VG03NC02

Material for professional use, install in compliance with the regulations in force at the place of installation.

For further information you can download the technical data sheet by clicking on the "Attachments" tab
