4-pole 16A DC MCB circuit breaker , "C" curve, protection against short circuits and overloads in renewable energy installations and photovoltaic systems, both domestic and industrial, as well as in solar pumping systems, battery systems, electric vehicle charging systems. High assigned breaking capacity, 10000A according to IEC/EN 60947-2. Maximum operating voltage 1000Vdc.
Highly reliable and high-performance device, allowing a high number of work cycles. Its selection must be made based on the application, taking into account the nominal current and the system voltage.
Technical characteristics:
- Manufacturer/Supplier: Hyundai Electric
- Manufacturer reference: HGD63-D4P016C
- Nominal intensity (In): 16A
- Number of poles: 4
- Characteristic curve: C
- Maximum operating voltage (Ue): 880/1000Vdc
- Breaking capacity (Icu): 10kA (Ics=75% Icu)
- Rated insulation voltage (Ui): 1000V
- Rated impulse withstand voltage (Uimp): 6kV
- Dielectric strength: 2.5kV
- Electrical / Mechanical endurance: 10000 / 20000 maneuvers
- Operating temperature: -40C...+55C
- Humidity: 95% RH
- Terminal size: 25mm²
- Maximum tightening torque: 2 Nm
- Protection class: IP20
- Weight: 0.4kg
- Visual contact indication: Red-ON, Green-OFF
- Mounting position: Vertical/Horizontal
- Housing material : Flame retardant molded thermoplastic
- Supports mounting of auxiliary elements: Yes
- Standards: CE; IEC/EN 60947-2
Professional use material, install in compliance with the regulations in force at the installation site.
