Three-phase contactor 12A 110Vac auxiliary contact closed NC

€10.67 Tax included

€8.82 tax excl.

Three-phase electric contactor equipped with high-capacity contacts, with 85% silver, for controlling electric motors, heating, lighting, ventilation, or general uses, 3 poles with a current capacity of 12A category AC3 or 25A category AC1, With 110Vac coil, the contactor is equipped with a closed auxiliary contact (NC).

Ref: CJX2-D1201-F7

Three-phase contactor diagram 12A 380V nc

Representative image for illustrative purposes, the item supplied will correspond to the indicated specifications.

No queries yet, leave the first!
Privacy
Shipments
Returns


Three-phase contactor (3 poles) of 12A in category AC3 or 25A in category AC1, the contactor is equipped with highly robust main contacts, manufactured with 85% silver, which makes it suitable for demanding applications for controlling electric motors , heating, lighting, ventilation and general use systems. The contactor is equipped with a closed (NC) auxiliary contact. The contactor can be fixed using screws or by DIN rail.

We have a wide range of accessories for the contactor.



General contactor characteristics:

  • Manufacturer/Supplier: Denor
  • Ref: CJX2-D1201-F7
  • Contactor rated current in AC3: 12A.
  • Number of contactor poles: 3.
  • Maximum thermal current Ith contactor: 25A.
  • Maximum contactor voltage: 660 V.
  • Quality of main contacts: 85% silver (Ag).
  • Maximum contactor power: 3~AC3 230V: 3.3 Kw.
  • Maximum contactor power: 3~AC3 400V: 5.5 Kw.
  • Contactor coil voltage: 110 Vac 50/60 Hz.
  • Auxiliary Contact integrated into the contactor: 1 Closed (NC).



Material for professional use, install in compliance with the regulations in force at the installation site.
