Starter capacitor with terminals adajusa
Starter capacitor with terminals adajusa

Starter capacitor 160-200uF 330Vac with terminals

€9.26 Tax included

7.65 tax excl.

CDI 160-200uF

Starter capacitor 160-200oF/330Vac type CD60,for single-phase electric motors, with PVC cover and terminal connection.

This type of capacitor has been designed exclusively for use as starter capacitors in single-phase electric motors.


reference: CDI 160-200 F/330Vac

Representative image for illustrative purposes, the supplied article is subject to the specifications indicated.

1 question about the product
Privacy
Shipments
Returns


Starter capacitor for single-phase electric motors, of non-polarized electrolytic type, with PVC sheath and connection by terminals.

The application of this type of capacitors is the start of single-phase electric motors, providing the necessary torque to the motor single-phase for its starting. They are non-polarized aluminum electrolytic capacitors for intermittent operation in starting circuits of single-phase electric motors, they should not be used for another application, nor be used in permanent regime as running capacitors.

Specifications:

  • Manufacturer/Supplier: OMU/Mixwill
  • Reference: CDI 160-200uF 330Vac
  • Application: Starter capacitor.
  • Capacity: 160-200uF.
  • Maximum nominal voltage: 330Vac.
  • Working temperature range: -40ºC.. +65ºC.
  • Nominal tolerance: 0..+20%.
  • Dissipation factor (20ºC, 120Hz): Tg δ ≤ 0.15
  • Electrical life (depends on voltage and time): 12500 ÷ 50000 times, according to ANSI/EIA-463-A standard
  • Test voltage: 1.25 times the rated voltage dudrante 2 seconds
  • Connection type: terminals
  • Dimensions (HxD): Ø45x85mm


Dimensiones condensadores arranque con terminales

This type of capacitors are for professional use, it can not be used as a permanent capacitor (march capacitor), it will deteriorate. It must be installed inside the terminal box of the engine, and following the regulations in force at the place of installation.

Questions

Question
¿Qué resistencia debo colocar para descarga?. Lo instalé para arranque de motor compresor, con un relé voltimétrico pero, se quema….ya me ha ocurrido 3 veces. Gracias
Answer
Buenos días.
El condensador que tiene que colocar en un motor monofásico  tiene que ser de las mismas características que tenía instalado originalmente.
 Saludos
 Adajusa
Daniel on 11/28/2022 21:58:33
